Power supply: AC90-AC240 50-60HZ

Maximum power: 500W

Number of main light beads: 12pcs 40w LED5060

Main light color: red, green, blue and white

Display screen: Chinese and English menus, button 1.77 color screen

Focusing system: overall single control control

Beam angle: 2.8-31 degrees

Spot angle: 5°-46°

Strobe: 1-25 times/sec

Dimming: Electronic dimming 0~100% linear adjustment, with gamma curve dimming frequency 1.2K~25K adjustable, macro dimming linear, stable and smooth without flickering, using stable constant current drive and power supply, suitable for video shooting

Vertical angle: 220° vertical direction (16 bit precision scanning) The Y-axis is driven by a high-speed silent 60 three-phase motor, which makes the operation faster and smoother, and can be automatically homing when a malfunction occurs, and the vertical speed is adjustable; Y-axis reversal function and reversal function; High-precision positioning using photoelectromagnetic coding

Control signal: DMX512, master-slave, voice-controlled or self-propelled program

Control Channels: 20/57CH 2 DMX Channel Modes

Power supply connection method: power input and output, maximum number of connections @ 2 units 230V, 1 unit 120V

Signal connection method: DMX512 input and output, the maximum number of 3-pin connections is 30 units

Supports the network protocol Artnet

Splicing method: can be spliced horizontally and quickly

Operating temperature: -10°C~45°C

Degree of protection: IP20

Product size: 103*10*29cm

Packing size: 109*18*35cm (one pack one)

Net weight: 16.6KG

Gross weight: 18.5KG
