YQ-ZN1260R
-
Voltage: AC100-240V 50/60HZ
Power supply: 1000W
Main beam: 60W * 12 LEDs 6065
Auxiliary LED: 432 1W dual color LED beads, white light+yellow gold light
Display screen: Chinese and English menus, touch 4 keys, 2.4-inch display screen
Focusing system: segmented independent single point single control
Beam angle: 2.8-31 degrees
Spot angle: 5 ° -55 °
Strobe frequency: 1-25Hz
Dimming: Electronic dimming with 0-100% linear adjustment, with gamma curve dimming frequency adjustable from 1.2K to 25K, macro command dimming with linear stability and smoothness without flicker, using stable constant current drive and power supply, suitable for video recording and shooting
Vertical angle: 220 ° in the vertical direction (16 bit precision scanning). The Y-axis adopts high-speed mute for faster and smoother operation. When there is a misoperation, it can automatically return to its original position, and the vertical speed is adjustable; Y-axis rotation function and reverse function; Using optical electromagnetic coding for high-precision positioning
Vertical control: independent single head control swing
Control signals: DMX512, RDM, master-slave, voice controlled or self-propelled program
Control channel: 26CH 59CH 128CH 182CH 314CH 329CH Default channel CH26
Power connection method: Power input/output, maximum connection quantity @ 2 units 230V, 1 unit 120V
Signal connection method: DMX512 input/output, maximum connection quantity of 30 3-core units
Support network protocol Artnet
Splicing method: Can be quickly spliced horizontally
Working temperature: -10 ° C~45 ° C
IP rating: IP22
Net weight: 26KG
Product size: 1000 * 139.76 * 295.5MM (excluding machine foot height)
Packaging size: 113 * 34 * 19CM (one pack, one)
